Specifications |
38
mm |
| Drilling Cap. (In Steel) | 38 mm |
| Column Diameter | 112 mm |
| Spindle Center to back Distance | 300 mm |
| Spindle nose to Table Distance | 830 mm |
| Spindle nose to base distance | 1050 mm |
| Table Travel | 250 mm |
| Taper in spindle | M.T.4 |
| Number of speed | 8 speed |
| Range of speed | 73 to 1800 RPM |
| Table size | 470 mm |
| Base size (Machined area) | 381 x 381 mm |
| Overall base size | 700 x 460 mm |
| Spindle travel | 300 mm |
| Column length | 1500 mm |
| Over all height with pulley guard | 2000 mm |
| V Belt section | B-62 |
| Nett Weight | 350 kg. |
| Motor 1440 RPM 3 Phase 440 Volts | 2 H.P. |
