Specifications |
13mm |
| Drilling Cap. (In Steel) | 13 mm |
| Column Diameter | 47 mm |
| Spindle Center to back Distance | 153 mm |
| Spindle nose to Table Distance | 370 mm |
| Spindle nose to base distance | 580 mm |
| Table Travel | 210 mm |
| Taper in spindle | M.T.1 (Stock Type) |
| Number of speed | 4 speed |
| Range of speed | 500 to 2825 RPM |
| Table size | 225 mm |
| Base size (Machined area) | 190 x 190 mm |
| Overall base size | 370 x 240 mm |
| Spindle travel | 70 mm |
| Column length | 775 mm |
| Over all height with pulley guard | 960 mm |
| V Belt section | FHP 2350 |
| Nett Weight | 40 kg. |
| Motor 1440 RPM 3 Phase 440 Volts | 0.50 H.P. |
