Specifications |
20mm |
| Drilling Cap. (In Steel) | 20 mm |
| Column Diameter | 75 mm |
| Spindle Center to back Distance | 200 mm |
| Spindle nose to Table Distance | 405 mm |
| Spindle nose to base distance | 635 mm |
| Table Travel | 340 mm |
| Taper in spindle | M.T.2 |
| Number of speed | 8 speed |
| Range of speed | 86 to 3360 RPM |
| Table size | 280 mm |
| Base size (Machined area) | 280 x 240 mm |
| Overall base size | 470 x 305 mm |
| Spindle travel | 127 mm |
| Column length | 1200 mm 900 mm |
| Over all height with pulley guard | 1100 mm |
| V Belt section | A-43 |
| Nett Weight | 100 kg. |
| Motor 1440 RPM 3 Phase 440 Volts | 1 H.P. |
