Specifications |
25
mm |
| Drilling Cap. (In Steel) | 25 mm |
| Column Diameter | 87 mm |
| Spindle Center to back Distance | 250 mm |
| Spindle nose to Table Distance | 830 mm |
| Spindle nose to base distance | 1050 mm |
| Table Travel | 270 mm |
| Taper in spindle | M.T.3 |
| Number of speed | 8 speed |
| Range of speed | 73 to 1800 RPM |
| Table size | 360 mm |
| Base size (Machined area) | 360 x 330 mm |
| Overall base size | 610 x 410 mm |
| Spindle travel | 252 mm |
| Column length | 1420 mm |
| Over all height with pulley guard | 1840 mm |
| V Belt section | B-52 |
| Nett Weight | 210 kg. |
| Motor 1440 RPM 3 Phase 440 Volts | 1 H.P. |
